APPLICATIONS
- For overedging and trimming various materials from lightweight fabrics such as chiffons, silk, suit lining, tricot, linen, cotton, general dress materials and woolens to heavyweight fabrics such as tweeds, coat cloth, jersey and denim
- Sew through denim as well as through the sheerest of fabrics without puckering
- Suitable for overedging such products as jackets, sweaters, dress and sports shirts, overalls, uniforms, jeans, work pants, dresses, jump suits, slips, negligees, pajamas, bathing suits, trousers and coats
- Suitable for general overedging, cross seaming, plain seaming, pintucking and braiding. You can ornament with pintuck or braid stitching and ornamental overlocking
FEATURES
- Two individually adjustable and replaceable loopers
- Easy color coded threading
- Counterbalanced mechanism. Suction cup feet for smooth, vibration-free operation
- Telescoping thread mast (convenient extension spool holders)
- Adjustable stitch length dial
- High-rise looper mechanism with presser foot lift up to 15/64" (6 mm)
- Heavy dutyupper and lower steel knife ensure sharp, clean cutting
- Easy thread tension control for a wide range of materials and threads
- Needle guard prevents needle from bending or breaking when stitching heavyweight materials such as denim etc.
ADDITIONAL INFORMATION
SPECIFICATIONS
| Number of Needles | 1 (Single) |
| Feeding Mechanism | Differential |
| Workspace | Standard Workspace |
| Standard or Full Function | Standard Functions |
| Speed, Max (S.P.M.) | 1200 |
| Stitch Type | 514 |
| Max Stitch Length | 4mm |
| Presser Foot Lift | 15/64" (6mm) |
| Needle Used | HAX1 |
| Clearance Under Foot | 4mm |
| Overedging Stitch Width | (3-6.7mm) |
| Cutter Width | Lft: 5.2~6.7mm - Rgt: 3.0~4.5mm |
| Standard Distance Between Needles | (2.2mm) |
| Differential Ratio | 1:05 ~ 1:2 |
| Dimensions | L.300 x W.310 x H.320 mm |
| Gross Weight in Shipping Carton | 20.9 lbs. (9.5kg) |
| Net Weight | 15.4 lbs (7.0kg) |
